Chapter 4 Replacing Motherboard Assembly Components 4-11
4.2.4 Replacing the Lower PCIe/XAUI Cards
Note – The maximum power of any one PCI card is 25 watts. PCIe/XAUI slots 0 and
1 are the only slots that support XAUI cards.
▼ To Remove the Lower PCIe/XAUI Cards
1. Prepare the server for card removal. See Section 4.1, “Powering Off and Powering
On the Server” on page 4-1.
2. Remove the PCI mezzanine and place it on an anti-static mat.
3. Loosen the appropriate card securing screws (
FIGURE 4-8).
4. Lift the PCI riser assembly (with PCI card attached) from the PCI mezzanine
(
FIGURE 4-8).
5. If installed, remove the card securing screw on the right side of the PCI card
faceplate (
FIGURE 4-8).
6. Remove the PCI card from the PCI riser assembly (
FIGURE 4-8).
