Sun Microsystems Netra T5220 - Replacing PCI-X 4 and Pcie 5 Cards; To Remove the PCI-X 4 and Pcie 5 Cards

Chapter 4 Replacing Motherboard Assembly Components 4-5
4.2.2 Replacing PCI-X 4 and PCIe 5 Cards
Note – The maximum power of any one PCI card is 25 watts. Only PCI-X slot 4 and
PCIe slot 5 accept long cards.
▼ To Remove the PCI-X 4 and PCIe 5 Cards
1. Prepare the server for PCI card removal. See Section 4.1, “Powering Off and
Powering On the Server” on page 4-1.
2. With the PCI mezzanine installed and cabled, identify which card is to be
removed.
3. Loosen the appropriate PCI card retainers and securing screws (
FIGURE 4-3).
The screws are captive and cannot be completely removed from the PCI
mezzanine.
