Chapter 2 Preparing for Service 2-5
■ PCIe 5
■ PCIe 2
■ PCIe 1/XAUI 1
■ PCIe 0/XAUI 0
■ Alarm
■ TTYA
■ SER MGT
■ NET MGT
■ USB 0
■ USB 1
■ NET 0
■ NET 1
■ NET 2
■ NET 3
■ Power supply 0
■ Power supply 1
3. If you are going to remove the CMA, also remove the cables from it.
4. Remove the server from the rack.
2.3.3 Removing the Server From the Rack
Remove the server from the rack prior to performing cold-swappable FRU
replacement procedures except the FB-DIMMs, PCI cards, and the service
processor.
Caution – The server weighs approximately 40 lb (18 kg). Two people are required
to dismount and carry the chassis.
1. Disconnect all the cables and power cords from the server.
2. From the front of the server, release the slide rail latches on each side.
Pinch the green latches as shown in
FIGURE 2-1.
