Servicing FRUs 101
In addition to the service procedures included here, you can see animations that
show how to remove and install the processors.
To play the Sun Server X4-2 Service Animations go to:
http://docs.oracle.com/cd/E36975_01/html/E49470/index.html
Caution – Ensure that all power is removed from the server before removing or
installing a processor. You must disconnect the power cables from the server before
performing these procedures.
Caution – These procedures require that you handle components that are sensitive
to electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 42.
Note – On single-processor systems, neither a heatsink nor a processor filler cover
are installed in the processor socket 1 (P1). To protect the delicate processor socket
pins, the cover that comes on the motherboard from manufacturing is left in place.
These following sections provide information to assist you when replacing a
processor:
■ “Selecting the Correct Processor Removal/Replacement Tool” on page 102
■ “Remove a Processor” on page 106
■ “Install a Processor” on page 112
Related Information
■ “Disconnect Cables From the Server” on page 39
■ “Take Antistatic Measures” on page 42
■ “Remove the Server From the Rack” on page 41
■ “Remove the Server Top Cover” on page 43
