Identifying the Server Ports 155
Related Information
■ “Server Back Panel View” on page 5
■ “Disconnect Cables From the Server” on page 39
■ “Reconnect Data Cables and Power Cords” on page 149
Serial Management Port
The serial management connector (labeled SER MGT) is an RJ-45 connector that can
be accessed from the rear panel. This port is the default connection to the server. Use
this port only for server management.
The following figure and table describe the SER MGT port pin signals.
TABLE: Network Management Port Signals
Pin Signal Description Pin Signal Description
1 Transmit Data + 5 Common Mode Termination
2 Transmit Data – 6 Receive Data –
3 Receive Data + 7 Common Mode Termination
4 Common Mode Termination 8 Common Mode Termination
TABLE: Default Serial Connections for Serial Port
Parameter Setting
Connector SER MGT
Rate 9600 baud
Parity None
Stop bits 1
Data bits 8
