■ Illuminate the Service Required status indicator (LED) on the server front and
back panels.
■ Identify the faulted component in the Open Problems table.
■ Record system information about the faulted component or condition in the event
log.
For further information about administering open problems that are detected and
reported by Oracle ILOM, refer to “Administering Open Problems” in the Oracle
Integrated Lights Out Manager (ILOM) 3.1 User’s Guide.
Related Information
■ Oracle Integrated Lights Out Manager (ILOM) 3.1 Documentation Library at:
http://www.oracle.com/goto/ILOM/docs
Monitoring System Components
The tables in this section identify the system components and describe the naming
conventions applied to the components of the Sun Server X4-2.
Each section corresponds to an IPMI entity ID and lists sensors, indicators, and
field-replaceable units (FRUs) related to that entity. The tables contain the following
fields:
■ Component Name – Shows the user-visible component name used in
management interfaces to refer to a specific sensor, indicator, or FRU. The IPMI
name is a shortened form of the component name, and is indicated by the
boldface portion of the component name.
■ IPMI Type – Indicates the type of sensor, indicator, or FRU represented.
■ Description – Describes of this particular component name reference.
■ Values – Defines the states of the sensor, indicator, or FRU entity, and any specific
units or values that are expected, if applicable.
Note – Some component names are hidden in the Oracle ILOM user interfaces.
These names are marked as hidden in the following tables. Further, as of Oracle
ILOM 3.1, the Oracle ILOM 3.0 legacy targets /SYS and /STORAGE have been
replaced by /System. Even though these legacy targets might be hidden, you can
still use them to issue commands. For information on legacy targets, see the ILOM
3.1 Documentation Library at http://www.oracle.com/goto/ILOM/docs.
This section includes information for the following server components:
