56 Sun Server X4-2 Service Manual • May 2014
To play the Sun Server X4-2 Service Animations go to:
http://docs.oracle.com/cd/E36975_01/html/E49470/index.html
See the following sections for more information:
■ “Power Supply Status Indicators” on page 56
■ “Remove a Power Supply” on page 57
■ “Install a Power Supply” on page 59
Related Information
■ “About Server and Component Status Indicators” on page 6
■ “Powering Down the Server” on page 33
Power Supply Status Indicators
Each power supply contains two status indicators (LEDs) on the back panel. The
following figure and table provide a description of the power supply status
indicators.
FIGURE: Power Supply Status Indicators
