153
Identifying the Server Ports
This section describes the pinouts of the server connectors.
Gigabit Ethernet Ports
The server has four auto-negotiating 100/1000/10,000BASE-T gigabit Ethernet (GbE)
system domain ports. All four Ethernet ports use a standard RJ-45 connector.
The transfer rates are shown in the following table:
The following figure and table describe the 10-GbE port pin signals.
Description Links
Learn about the Gigabit Ethernet ports. “Gigabit Ethernet Ports” on page 153
Learn about the network management
port.
“Network Management Port” on page 154
Learn about the serial management port. “Serial Management Port” on page 155
Learn about the video connector. “Video Connector” on page 157
Learn about USB ports. “USB Ports” on page 158
TABLE: Ethernet Port Transfer Rates
Connection Type IEEE Terminology Transfer Rate
Fast Ethernet 100BASE-TX 100 Mbps
Gigabit Ethernet 1000BASE-T 1,000 Mbps
10 Gigabit Ethernet 10GBASE-T 10,000 Mbps
