144 Sun Server X4-2 Service Manual • May 2014
See the following procedure for instructions for removing and installing the server
filler panels:
■ “Remove and Install Filler Panels” on page 144
Related Information
■ “Servicing CRUs That Do Not Require Server Power-Off” on page 45
■ “Servicing CRUs That Require Server Power-Off” on page 61
▼ Remove and Install Filler Panels
● See the procedures in the following table to remove and install filler panels for
storage drives and PCIe cards.
Filler Panel
Type Removal Procedure Installation Procedure
Storage
Drive
1. Locate the storage drive filler panel
to be removed from the server.
2. To unlatch the storage drive filler
panel, press the release lever button,
and then pull the lever out into a
fully opened position.
3. To remove the filler panel from the
slot, hold the opened release lever,
and gently slide the filler panel
toward you.
1. Locate the vacant storage drive
module slot in the server, and then
ensure that the release lever on the
filler panel is fully opened. Slide
the filler panel into the vacant slot
by pressing the middle of the filler
panel faceplate with your thumb or
finger.
2. The release lever will close as it
makes contact with the chassis. Do
not slide the filler panel in all the
way. Leave the filler panel out
approximately 0.25 to 0.50 inch (6
to 12 mm) from the opening.
3. Using your thumb or finger, press
on the middle of the filler panel
faceplate until the release lever
engages with the chassis.
4. Close the release lever until it
clicks into place and is flush with
the front of the server
