80 Sun Server X4-2 Service Manual • May 2014
e. Power on the server.
See “Power On the Server” on page 150.
Verify that the Power/OK status indicator is steady on.
8. Use Oracle ILOM to clear the server PCIe riser fault.
If the PCIe riser fault message in Oracle ILOM is not cleared under Open
Problems, you must manually clear the fault in Oracle ILOM. For instructions for
manually clearing a PCIe riser fault, see the procedure "Clear Faults for
Undetected Replaced or Repaired Hardware Components" in the Oracle Integrated
Lights Out Manager (ILOM) 3.1 User’s Guide in the Oracle Integrated Lights Out
Manager (ILOM) 3.1 Documentation Library at
http://www.oracle.com/goto/ILOM/docs.
Related Information
■ “Remove a PCIe Riser From PCIe Slot 1 or 2” on page 76
▼ Remove a PCIe Riser From PCIe Slots 3 and 4
1. Prepare the server for service.
a. Power off the server and disconnect the power cords from the power
supplies.
See “Powering Down the Server” on page 33
b. Extend the server to the maintenance position.
See “Extend the Server to the Maintenance Position” on page 39.
c. Attach an antistatic wrist strap to your wrist and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 42.
d. Remove the server top cover.
See “Remove the Server Top Cover” on page 43.
2. If there is a PCIe card installed in the riser, disconnect any external or internal
cables.
Note – Do not disconnect the SAS cable from the internal host bus adapter card until
after you have removed the riser from the server.
3. Open the green-tabbed latch located on the rear of the server chassis next to
PCIe slot 3 to release the rear bracket on the PCIe card [1].
