Disk Backplane Components
The following table lists the disk backplane (DBP) components.
Related Information
■ “System Chassis Components” on page 229
■ “Cooling Unit Components” on page 231
■ “Memory Device Components” on page 232
■ “Power Unit Components” on page 233
■ “Processor Components” on page 235
■ “System Board Components” on page 235
■ “System Firmware Components” on page 237
■ “Hard Disk Drive Components” on page 238
Memory Device Components
The following table lists the memory device components.
Component Name
(Oracle ILOM CLI
Targets) IPMI Type Description
/SYS/DBP[0-2] FRU Disk backplane FRUs for a multiple DBP configuration
/SYS/DBP FRU Disk backplane FRU for a single DBP configuration
Component Name (Oracle ILOM CLI
Targets) IPMI Type Description
Values
(if applicable)
/SYS/MB/P[0-1]/D[0-7] FRU Host CPU
DIMM FRU
