246 Sun Server X4-2 Service Manual • May 2014
Related Information
■ “System Chassis Components” on page 229
■ “Cooling Unit Components” on page 231
■ “Disk Backplane Components” on page 232
■ “Memory Device Components” on page 232
■ “Power Unit Components” on page 233
■ “Processor Components” on page 235
■ “System Board Components” on page 235
■ “Hard Disk Drive Components” on page 238
Fan Events
The following table lists fan events.
SNMP Message: sunHwTrapComponentError
Oracle ILOM Message: ACPI_ON_WORKING DEASSERT
Severity and Description: Major; A sensor has detected an error. This generic
’component’ trap is generated when the SNMP agent does not recognize the
component type.
/SYS/ACPI
SNMP Message: sunHwTrapComponentError
Oracle ILOM Message: ACPI_SOFT_OFF ASSERT
Severity and Description: Major; A sensor has detected an error. This generic
’component’ trap is generated when the SNMP agent does not recognize the
component type.
/SYS/ACPI
SNMP Message: sunHwTrapComponentError
Oracle ILOM Message: ACPI_SOFT_OFF DEASSERT
Severity and Description: Major; A sensor has detected an error. This generic
’component’ trap is generated when the SNMP agent does not recognize the
component type.
/SYS/ACPI
Messages and Descriptions Sensor Name
