112 Sun Server X4-2 Service Manual • May 2014
▼ Install a Processor
Caution – Processors should be installed only by an Oracle qualified service
technician.
Caution – Processor removal and replacement must be done using the correct
removal/replacement tool; otherwise, damage might result to the processor or the
processor socket. For information on how to select the correct removal/replacement
tool, see “Selecting the Correct Processor Removal/Replacement Tool” on page 102.
Caution – Be careful not to touch the processor socket pins. The processor socket
pins are very fragile. A light touch can bend the processor socket pins and damage
the board beyond repair. Always use the processor removal/replacement tool to
remove and replace the processor.
1. Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 42.
2. Unpack the replacement processor and place it on an antistatic mat.
3. Ensure that the replacement processor is identical to the processor that was
removed.
For a description of the processors supported by the server, see the Sun Server
X4-2 Installation Guide, “Server Components” on page 20.
4. Ensure that the two processor ILM assembly levers and the ILM assembly load
plate are in the fully open position.
For instructions for opening the processor ILM assembly levers and the load plate,
see Step 6 through Step 8 of “Remove a Processor” on page 106.
5. To install the replacement processor into the processor removal/replacement
tool, acquire the correct removal/replacement tool and perform the following
steps:
Caution – Before installing the processor, ensure that you are using the correct
color-coded processor removal/replacement tool. For information on how to select
the correct processor removal/replacement tool, see “Selecting the Correct Processor
Removal/Replacement Tool” on page 102.
