Servicing FRUs 113
a. Press the button in the center of the tool to the down position (see FIGURE:
Installing a Processor on page 114 [1]).
b. Turn the tool upside down, grasp the processor by its front an back edges and
position the processor (circuit side up) in the tool so that the triangle on the
corner of the processor aligns with the triangle on the side of the processor
removal/replacement tool [2].
c. Lower the processor into the tool and press the tool release lever to release
the center button and engage the processor [3].
An audible click indicates that the processor is locked in place.
d. Properly position the tool over the processor socket and lower it into place
[4].
To properly position the tool in the processor socket, rotate the tool until the
green or pink triangle (depending on which color-coded tool is being used) on
the side of the tool is facing the front of the server and it is over the left side of
the processor socket (when viewing the server from the front) and lower the
tool into the processor socket.
e. Press the center button in the tool down to release the processor so that it is
installed in the socket [5].
f. Remove the processor removal/replacement tool [6].
Caution – The following figure shows the green color-coded processor
removal/replacement tool. If you are installing a 12-core processor, you must use the
pink color-coded processor removal/replacement tool; otherwise, damage might
result to the processor or the processor socket. For information on how to select the
correct processor removal/replacement tool, see “Selecting the Correct Processor
Removal/Replacement Tool” on page 102.
