Sun Oracle Sun Server X4-2 - Ethernet Ports Status Indicators

12 Sun Server X4-2 Service Manual • May 2014
Related Information
■ “Network Management Port” on page 154
■ “Front Panel Controls and Indicators on a System With Eight 2.5-inch Drives” on
page 3
■ “Front Panel Controls and Indicators on a System With Four 2.5-inch Drives and
DVD Drive” on page 4
■ “Server Back Panel View” on page 5
■ “Servicing Power Supplies (CRU)” on page 55
Ethernet Ports Status Indicators
The server has four Ethernet ports (NET 3, NET 2, NET 1, and NET 0). There are two
status indicators on each port. These indicators are visible from the rear of the server.
Note – Ethernet ports NET 2 and NET 3 are nonfunctional in single-processor
systems.
TABLE: Network Management Port Status Indicators
Status
Indicator
Name Location Color State and Meaning
Link speed Top left Bicolored:
Amber/Green
• Amber ON – 10BASE-T link.
• Green ON – 100BASE-T link.
• OFF – No link or link down.
• FLASHING – No function.
Activity Top right Green • ON – No function.
• OFF – No activity.
• FLASHING – Packet activity.
