BIOS Setup Utility Menu Options 207
Internal Port 1 Disabled/Enabled Enabled Enable or disable USB Port 5.
SERIAL PORT CONSOLE
REDIRECTION
Provides the capability to
redirect console output/input to
the serial port. Graphic output is
not redirected. BIOS serial
console redirection lets you
monitor BIOS POST messages
and navigate the BIOS Setup
Utility menus and Option ROMs
from a terminal connected to the
server using a serial connection.
External Serial Port System/BMC System Control whether the external
serial port connects to the
Baseboard Management
Controller (BMC) or directly to
the system. Set to BMC for serial
link management.
EMS Console Redirection Disabled/Enabled Disabled Enable or disable console
redirection for Windows
Emergency Management Service
(EMS) administration.
Console Redirection Disabled/Enabled Enabled Enable or disable console
redirection.
Terminal Type VT100/
VT100+/
VT-UTF8/
ANSI
VT100+ Select the emulation for the
terminal:
• VT100: ASCII character set.
• VT100+: Extends VT100 to
support color, function keys,
etc.
• VT-UTF8: Uses UTF8 encoding
to map Unicode characters
onto one or more bytes.
• ANSI: Extended ASCII
character set.
Bits per Second 9600/
10200/
57600/
115200
9600 Select the serial port
transmission speed. The speed
must be matched on the
connecting serial device. Long or
noisy lines require lower speeds.
Data Bits 07/
08/
11
8 Select the data bits.
TABLE: BIOS Advanced Menu Options (Continued)
Setup Options Options Defaults Description
