236 Sun Server X4-2 Service Manual • May 2014
/SYS/MB/PCIE[1-6]/PRSN
T
Discrete
sensor
Option card inserted
into PCIe slot
01h-ENTITY_PRESE
NT,
02h-ENTITY_PRESE
NT
/SYS/MB/T_OUT_ZONE[
0-2]
Threshold
sensor
Cooling zone exhaust
temperature
Degrees C
/SYS/MB/T_IN_ZONE[0-2
]
Threshold
sensor
Cooling zone inlet
temperature
Degrees C
/SYS/MB/T_CORE_NET01
,
/SYS/MB/T_CORE_NET23
Threshold
sensor
Gigabit Ethernet
controller die
temperature
Degrees C
/SYS/MB/T_IN_PS[0,1] Threshold
sensor
PSU inlet temperature Degrees C
/SYS/MB/SASEXP FRU SAS expander FRU
/SYS/MB/SASEXP/PRSNT Discrete
sensor
SAS expander board
presence
01h-ENTITY_PRESE
NT,
02h-ENTITY_PRESE
NT
/SYS/MB/SASEXP/T_COR
E
Threshold
sensor
SAS expander board
temperature
Degrees C
/SYS/MB/RIO FRU Rear I/O board
/SYS/MB/RIO/PRSNT Discrete
sensor
Rear I/O board
presence
01h-ENTITY_PRESE
NT,
02h-ENTITY_PRESE
NT
/SYS/MB/CONNBD FRU Connector board on
QPI bridge
/SYS/MB/CONNBD/PRS
NT
Discrete
sensor
Connector board
presence
01h-ENTITY_PRESE
NT,
02h-ENTITY_PRESE
NT
/SYS/SP FRU Service processor FRU
/SYS/SP/OK Indicator SP OK LED Color: Green
Location: Front
panel
On: SP is operating.
Component Name (Oracle ILOM
CLI Targets) IPMI Type Description
Values
(if applicable)
