Servicing CRUs That Require Server Power-Off 63
In addition to the service procedures included here, you can see animations that
show how to remove and install DIMMs.
To play the Sun Server X4-2 Service Animations go to:
http://docs.oracle.com/cd/E36975_01/html/E49470/index.html
The Sun Server X4-2 supports a variety of DDR3 DIMM configurations that can
include quad-rank (QR), dual-rank (DR), and single-rank (SR) DDR3 DIMMs.
Note – While single-rank DIMMs can be installed in the Sun Server X4-2, Oracle
does not offer any single-rank DIMMs for purchase, either as factory-installed
options or as separately orderable options.
Caution – These procedures require that you handle components that are sensitive
to electrostatic discharge. This sensitivity can cause the components to fail. To avoid
damage, ensure that you follow antistatic practices as described in “Take Antistatic
Measures” on page 42.
Caution – Ensure that all power is removed from the server before removing or
installing DDR3 DIMMs, or damage to the DDR3 DIMMs might occur. You must
disconnect all power cables from the system before performing these procedures.
The following sections provide information to assist you when replacing or
upgrading a DIMM:
■ “DIMM and Processor Physical Layout” on page 64
■ “DIMM Population Example for Optimal System Performance” on page 65
■ “DIMM Population Rules” on page 67
■ “DIMM Rank Classification Labels” on page 69
■ “Inconsistencies Between DIMM Fault Indicators and the BIOS Isolation of Faulty
DIMMs” on page 70
■ “Using the Fault Remind Button” on page 70
■ “Identify and Remove a Faulty DIMM” on page 71
■ “Install a DIMM” on page 73
