SVAN 971 User Manual – Appendixes
132
45
Result[3][1]
Lxpeak
1
value in the 3
rd
profile (*100 dB)
46
Result[3][2]
LxyE
23
value in the 3
rd
profile (*100 dB)
47
Result[3][3]
maximal value (Lxymax
2
) in the 3
rd
profile (*100 dB)
48
Result[3][4]
minimal value (Lxymin
2
) in the 3
rd
profile (*100 dB)
49
Result[3][5]
Lxy
2
value in the 3
rd
profile (*100 dB)
50
Result[3][6]
Lxyeq
23
value in the 3
rd
profile (*100 dB)
51
Result[3][7]
Lden value in the 3
rd
profile (*100 dB)
52
Result[3][8]
Ltm3 value in the 3
rd
profile (*100 dB)
53
Result[3][9]
Ltm5 value in the 3
rd
profile (*100 dB)
54
Result[3][10]
reserved
55
Result[3][11]
reserved
56
UnderRes[3]
under-range value in the 3
rd
profile
57..58
ULTime[3]
reserved
59..60
PTC[3]
reserved
61
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
…
…
…
1
x - depends of the filter type for Peak result calculation in selected profile: A, C, Z, B (cf.
Tab. B.1.12)
2
x - depends of the filter type in selected profile: A, C, Z, B (cf. Tab. B.1.12)
y - depends of the detector type in selected profile: I (imp.), F (fast), S (slow) (cf. Tab. B.1.12)
3
y - only for exponential detector's type (cf. Tab. B.1.6)
Table B.1.18_DM. Main results in DOSE METER mode (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn07
[07, nn=block’s length]
1
0x0307
[used_profile, profile’s mask]
2
0xmm08
[08, mm=sub-block’s length]
3..4
MeasureTime
time of the measurement
5
Result[1][1]
Lxpeak
1
value in the 1
st
profile (*100 dB)
6
Result[1][2]
LxyE
23
value in the 1
st
profile (*100 dB)
7
Result[1][3]
maximal value (Lxymax
2
) in the 1
st
profile (*100 dB)
8
Result[1][4]
minimal value (Lxymin
2
) in the 1
st
profile (*100 dB)
9
Result[1][5]
Lxy
2
value in the 1
st
profile (*100 dB)
10
Result[1][6]
Lxyeq
23
value in the 1
st
profile (*100 dB)
11
Result[1][7]
Lc-a (LCeq-LAeq) value (*100 dB)
