Result[1][8]
Ltm3 value in the 1
st
profile (*100 dB)
13
Result[1][9]
Ltm5 value in the 1
st
profile (*100 dB)
14
Result[1][10]
LAV value in the 1
st
profile (*100 dB)
15
Result[1][11]
TLAV value in the 1
st
profile (*100 dB)
16
UnderRes[1]
under-range value in the 1
st
profile
17..18
ULTime[1]
ULT value in the 1
st
profile (sec.)
19..20
PTC[1]
PTC value in the 1
st
profile
21
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
22
0xmm08
[08, mm=sub-block’s length]
23..24
OVL
overlad time
25
Result[2][1]
Lxpeak
1
value in the 2
nd
profile (*100 dB)
26
Result[2][2]
LxyE
23
value in the 2
nd
profile (*100 dB)
27
Result[2][3]
maximal value (Lxymax
2
) in the 2
nd
profile (*100 dB)
28
Result[2][4]
minimal value (Lxymin
2
) in the 2
nd
profile (*100 dB)
29
Result[2][5]
Lxy
2
value in the 2
nd
profile (*100 dB)
30
Result[2][6]
Lxyeq
23
value in the 2
nd
profile (*100 dB)
31
Result[2][7]
reserved
32
Result[2][8]
Ltm3 value in the 2
nd
profile (*100 dB)
33
Result[2][9]
Ltm5 value in the 2
nd
profile (*100 dB)
34
Result[2][10]
LAV value in the 2
nd
profile (*100 dB)
35
Result[2][11]
TLAV value in the 2
nd
profile (*100 dB)
36
UnderRes[2]
under-range value in the 2
nd
profile
37..38
ULTime[2]
ULT value in the 2
nd
profile (sec.)
39..40
PTC[2]
PTC value in the 2
nd
profile
41
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
42
0xmm08
[08, mm=sub-block’s length]
43..44
Reserved
reserved
45
Result[3][1]
Lxpeak
1
value in the 3
rd
profile (*100 dB)
46
Result[3][2]
LxyE
23
value in the 3
rd
profile (*100 dB)
47
Result[3][3]
maximal value (Lxymax
2
) in the 3
rd
profile (*100 dB)
48
Result[3][4]
minimal value (Lxymin
2
) in the 3
rd
profile (*100 dB)
49
Result[3][5]
Lxy
2
value in the 3
rd
profile (*100 dB)
50
Result[3][6]
Lxyeq
23
value in the 3
rd
profile (*100 dB)
51
Result[3][7]
reserved
