SVAN 971 User Manual – Appendixes
134
52
Result[3][8]
Ltm3 value in the 3
rd
profile (*100 dB)
53
Result[3][9]
Ltm5 value in the 3
rd
profile (*100 dB)
54
Result[3][10]
LAV value in the 3
rd
profile (*100 dB)
55
Result[3][11]
TLAV value in the 3
rd
profile (*100 dB)
56
UnderRes[3]
under-range value in the 3
rd
profile
57..58
ULTime[3]
ULT value in the 3
rd
profile (sec.)
59..60
PTC[3]
PTC value in the 3
rd
profile
61
UnitFlags
flags word for measurement cycle (definition in table B.1.6)
…
…
…
1
x - depends of the filter type for Peak result calculation in selected profile: A, C, Z, B (cf.
Tab. B.1.12)
2
x - depends of the filter type in selected profile: A, C, Z, B, LF (cf. Tab. B.1.12)
y - depends of the detector type in selected profile: I (imp.), F (fast), S (slow) (cf. Tab. B.1.12)
3
y - only for exponential detector's type (cf. Tab. B.1.6)
Table B.1.19. Statistical levels (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn17
[17, nn=block’s length]
1
0xpprr
[pp=used_profile, rr=profile’s mask]
2
N_stat_level
number of statistical levels = N
3+i*(pp+1)
nn[i]
number of the Lnn statistics;
i=0..N-1
3+i*(pp+1)+
p
Lnn[i,p]
value of the Lnn statistics
for profile p (p=1..pp) (*100 dB)
…
…
…
Table B.1.20. 1/1 OCTAVE analysis results (saved in Summary Results Record)
Word
number
Name
Comment
0
0xnn0E, 0xnn26,
0xnn27, 0xnn30
[block_id, nn=block_length]
0xnn0E - averaged spectrum results,
0xnn26 - min. spectrum results,
0xnn27 - max. spectrum results
0xnn30 - peak spectrum results
1
0x0101
[used_profile, profile’s mask]
2
LowestFreq
the lowest 1/1 OCTAVE frequency (*100 Hz): 3150 (AUDIO BAND)
3
NOct
number of 1/1 OCTAVE values: 10 (AUDIO BAND)
