INTRODUCTION
1.3. SETUP
1.3.1. Check parts
1x
Container spout kit
No.6
blue (Diluent)
033-0403-1 for pocH-pack 65
033-0405-9 for pocH-pack 65XL
• Move and handle carefully.If the packagingis
damaged,openthepackageinthepresenceofa
representativefromthelogisticscompany.
Pleasestatethedamageclearlyonthereceipt.
•Prerequisites for installation
-Ensurethatpowerisavailable.
-Placeonatablewhich cansupportthedevice’s
weight(17.5kg).
-Providesufcientspaceforpropercooling,main-
tenanceorservicework.
Thedistance from therightside,rear,and top
panelstowallsshouldbeatleast15cm(6In.).
-The instrument must beinstalled in a dry and
dust-free location.
-Devicemustbeprotectedagainstwater.
•Safety instructions for installation
-
Donotexposetheinstrumenttoexcessive tem-
peratureuctuationanddirectsunlight.
-Avoidshockandvibrations.
-Theinstallationlocationmustbewellventilated.
-Avoidinstallationneardevicescausingpotential
interference,suchas radios,centrifuges, com-
putermonitors,wirelesscommunicationequip-
ment or similar devices.
-Installation of thisinstrument in places where
chemicals are stored or hazardous gasmay be
present is not permitted.
*1Thispartisforopenpipette.
*2The wastebottleassy POCH(C1/WITHFSW
 033-0041-1)mightbenecessaryincaseofusing
pocH-pack 65XL (optional).
Important
1x
Sampletubeadapter
green(Controlblood)
442-3051-2
1x
Sampletubeadapter
red(S-MONOVETTE
SARSTEDT2.7mL)
AA155506
1x
Thermalpaper
CL5840
AH042068
1x
Transducerbrush
No. 3
462-3523-6
1x
Tubepolyurethane
4MMID×6MMOD
442-5338-7
2x
MinipipetteNo.10
(1mL)
423-1776-2
1x
Powercord
4622-007-0092(Europe)
265-4 731-5
1x
Wiringcord
No.2188
963-0801-5
1x
CoiltubeSS-10
2 6 6 - 7 110 - 2
1x
Container spout kit
No.7
purple(Lysingreagent)
033-0414-2
1x
Sampletubeadapter
13mmSysmexwhite
CJ296916
1x
Screwdriver(-)
A6012Standard
462-2388-3
•InstructionsforUse
 CG184474
SYSTEM OVERVIEW, TECHNICAL INFORMATION & SETUP
INTRODUCTION
1x
ContainerSpoutKit
No.6
red(Waste)
033-0404-5
1x
Wastebottle
assyPOCH
(C1/WITHFSW)
033-0041-1
*2
1x
Container spout kit
No.7
purple(Lysingreagent)
033-0412-5
2x
Fuse02153.15MXP
250VT3.15AH
AL039459
1x
Screwdriver(+)
A6002Philips
462-2387-0
1x
SpacerNo.192
(13 mm)
365-9452-9
*1
