SYSMEX pocH-100i - 1.2. Technical Information; 1.2.1. Performance Characteristics & Specifications

2345678
1
1-6
Ambient temperature
15 °C to 30 °C (ideal operating temperature at 23 °C)
(59 °F – 86 °F)
Relative humidity 30% to 85%
Main Unit dimensions
Width: 185 mm (7.3 in)
Depth: 460 mm (18.1 in)
Height: 350 mm (13.8 in)
Weight: approx. 14 kg (30.8 lbs)
Power supply 100-240 VAC (±10%), 50/60 Hz
Power consumption 150 VA or less
Analysis Parameters see Chapter "Abbreviations/Units".
Display range
WBC: 0.0 – 299.9 (× 10
3
/μL)
RBC: 0.00 – 19.99 (× 10
6
/μL)
HGB: 0 – 25.0(g/dL)
PLT: 0 – 1999 (× 10
3
/μL)
Background limits
WBC: 0.3 (×10
3
/μL)
RBC: 0.02 (× 10
6
/μL)
HGB: 0.1 (g/dL)
PLT: 10 (× 10
3
/μL)
Analysis time Approx. 148 seconds (After starting an analysis until displaying the analysis report)
Analysis principle
WBC: DC detection method
RB C / P LT: Hydrodynamic Focusing DC detection method
HGB: Non-cyanide HGB method
Required temperature compensation Approx. 512 BTU/h (Approx. 130 kcal/h)
Class of electric shock protection measures Class
Ⅰ
Equipment
EMC characteristics Conforms with IEC 61326-1 (Class B, Group 1, Industrial environment)
Safety Conforms with IEC 61010-1 (Overvoltage category
Ⅱ
,Pollutiondegree2,Portableequipment)
1.2. TECHNICAL INFOR MATION
1.2.1. Performance characteristic - Specifications
pocH-100
i
Revised June 2008
SYSTEM OVERVIEW, TECHNICAL INFORMATION & SETUP
INTRODUCTION
