In this section, only the settings relevant
for installation are described. For details
on all possible settings see "Settings &
Calibration" page 5-1.
Insert cable into socket.
Insert cable into socket.
Insert cable into an AC outlet.
Insert cable into an AC outlet.
1.3.6. Power cord
Switch ON.
Switch ON.
The instrument performs:
1. a rinse cycle
2. a background check
Ready after 6-11 minutes.
Ready after 6-11 minutes.
1.3.7. Switch ON
When the main switch is turned ON the first time, supply the reagents into the
instrument.
The instrument runs on 100-250V AC,
50/60Hz.
Important
Note
Improper grounding of the instrument
can cause electrical shock.
Danger, electric shock
pocH-100
i
Revised June 2008
INTRODUCTION
SYSTEM OVERVIEW, TECHNICAL INFORMATION & SETUP
