V/D
S
ERIES
E
LECTRICAL ASSEMBLIES
4-24 Revision: 2.1
4.2.8 SD card circuit board
• See chapter 4.1.8 oben.
4.2.9 Toroidal transformer
• See chapter 4.1.11 oben.
4.3 Control unit Pan1002
4.3.1 V/D-40 – 200
A 4-pin connector connects JP4 on the control unit to JP13 or JP8 on the
digital circuit board DS1002.
It has its own CPU with its own software.
The control unit can only be replaced as a complete unit (see
chapter 3.5.2 above)
Make sure that the messages are displayed correctly on the
control unit!
After replacing the control unit, the language must be set again
in the Service menu.
On pass-through autoclaves (D-2D), the side on which the control unit is
located is defined under ChangeAddress:
Front = On device side
Back = On clean room side
4.3.2 D-23
A 4-pin connector connects JP4 on the control unit to JP2/JP1 on the D-23
digital circuit board.
It has its own CPU with its own software.
The control unit can only be replaced as a complete unit (see
chapter 3.5.2 above)
Make sure that the messages are displayed correctly on the
control unit!
After replacing the control unit, the language must be set again
in the Service menu.
