V/D
S
ERIES
M
ECHANICAL ASSEMBLIES
Revision: 2.1 3-31
Door seal maintenance
The door is sealed from the sterilisation chamber by the lip seal. The seal
must be kept clean to ensure correct functionality.
Note
Once the door seal has been partially pulled out, it cannot be
pushed back in. In this case, proceed as described under
“Replacement”.
Service interval Annual maintenance
Have available Measuring gauge
Maintenance:
• Check that the screws of the fixing plates are correctly seated.
• Check if the seal is damaged, brittle or hardened.
Fig. 11: Measuring the distance
• Measure the distance from the inside wall of the door to the lip. If the
distance is less than 11 mm, you must replace the door seal.
Replacement:
Necessary tools 3 mm Allen key
Have available New seal
