V/D
S
ERIES
M
ECHANICAL ASSEMBLIES
3-32 Revision: 2.1
Both the screws and the door are made of stainless steel. To
prevent jamming, the threads are treated at the factory with an
aluminium paste and must only be fastened hand-tight.
• Open the door.
• Loosen the screws on the fixing plate by two to three turns (do not
remove them).
Fig. 12: Pulling out the door seal
• Pull out the door seal.
• Insert a new door seal.
Tighten the fixing plate.
