V/D
S
ERIES
S
ERVICE SOFTWARE
6-20 Revision: 2.1
Make sure that auto mode is activated before exiting this
dialogue
The device controller only monitors the outputs after the device
is returned to auto mode, thus guaranteeing safe operation.
Auto mode is automatically activated!
Auto mode is activated automatically when the device is
switched on and off.
The following options are available:
Digital Outputs
table
Displays the state of each digital output
(: Off (grey), : On (green)).
In manual mode, double-click the status display to switch
the corresponding output on or off.
Analog Inputs
table
Displays the current values of the analogue inputs.
Go to manual
mode / go to auto
mode utton
Switches between auto mode (digital outputs correspond
to the program status of the device) and manual mode.
Always reactivate auto mode before exiting the
dialogue in order to return control to the device
controller!
Spin
check box
Switches all digital outputs on and off in succession for
testing purposes.
6.2.9 System
You can select individual device data parameters and change them
manually. These are:
− “Clock”, to set the time
− “Hardware”, to set the machine-specific parameters
− “Errors”, to view and print out the last ten errors
− “Programs”, to view and edit the program names and access level
Clock
Click “Clock” to synchronise the time on the device with the time on the
PC.
A dialogue appears with the following options.
