V/D
S
ERIES
M
ECHANICAL ASSEMBLIES
Revision: 2.1 3-51
• Carefully loosen and remove the rubber cover.
• Pull out the pin connectors.
• Plug the pin connectors into the new control unit.
• Pull the rubber cover over the new control unit.
• Spot-fix the rubber cover using superglue.
• Reinstall the control unit in reverse order.
3.6 Radial fan
3.6.1 Position and function
The optional radial fan is used to support cooling and the optimum
distribution of the steam-air mixture in the sterilisation chamber.
The motor is located on the outside of the door or the rear of the
sterilisation chamber.
It drives the fan wheel on the inside through a magnetic coupling. To
ensure that it runs smoothly, the motor must be carefully centred.
The fan wheel is press-fitted on the shaft. When required, only the
complete fan wheel with bearing can be replaced.
3.6.2 Maintenance tasks
Necessary tools 8 mm spanner, long-nosed pliers
Have available Two screwdrivers
Pipe extension, if necessary
Adjusting the fan motor/rear wall
• Remove the door cladding.
• Slightly loosen the fastening screws on the motor.
• Switch on the autoclave.
• In the Service -> Manual output set menu, set the
CircPump output to switch on the fan.
• Centre the motor (thus keeping the vibration as low as possible).
• Tighten the fastening screws.
Replacing the fan wheel
• Open the door.
• Pull the flexible temperature sensor out of its mounting and secure it.
