3.1 Removing and attaching service doors
3.1.1 V series
The panels on the front, rear and sides (since 2010) of the device are
designed as service doors which can be removed in order to carry out
maintenance.
Removing the doors on the front and rear
There is a lock on the service door which can be opened with the key
provided.
• Turn the key by a quarter-turn to free the lock.
• Remove the service doors from the device.
Removing the side sections
Service doors are found on the left and right side of the device, and can be
removed by detaching the three screws underneath the device.
3.1.2 D-45 – 200
Removing the rear
There is a lock on the service door which can be opened with the key
provided.
• Turn the key by a quarter-turn to free the lock.
• Remove the service door from the device.
Removing the side sections
• Unscrew the fastening nuts.
• Push back the side section by approx. 2 cm and remove it by pulling it
downwards.
