V/D
S
ERIES
S
ERVICE SOFTWARE
Revision: 2.1 6-13
Note the direction of communication
In the Systec service software,
always means
transmission from the PC to the device. The original data on the
device is overwritten.
The following options are available:
S19 file location
Select the S19 file to be used.
Click the associated button “...” to open a standard
Windows file selection dialogue.
Download Code
check box
If activated, the current software version is updated.
If the code is updated without text strings, then the
software version number is not changed. You may
have to do this manually afterwards (see Hardware)!
Download
Parameters
check box
If activated, the entire current set of parameters is
overwritten.
Download Text
Strings
check box
If activated, the control unit texts are replaced.
Proceed as follows:
• Select the S19 file.
• Select the parts of the firmware you want to update.
• Click “Download” to execute the update.
A progress bar appears where you can follow the progress of the
download.
