V/D S ERIES
M ECHANICAL ASSEMBLIES
3-40 Revision: 2.1
1
2
5
6
3
4
Fig. 17: Closed position
1 Magnet
2 Reed contact
3 Spindle
4 Gear motor
5 Lower lock catch
6 Upper lock catch
5 mm
7
8
Fig. 18: Secured position
7 Locking plate
8 Safety ramp
