V/D S ERIES
M ECHANICAL ASSEMBLIES
Revision: 2.1 3-63
Height and length of the water level electrodes:
Height of
H electrode*
Height of
L electrode*
Length Height measurement
DX-23/45
VX-40/55
75 mm 65 mm 100 mm
From top edge of water
level electrode to top
edge of steam
generator
DX-65 – 200
VX-65 – 150
65 mm 45 mm 145 mm
DE/DB-23
32 mm 25 mm 100 mm
From top edge of water
level electrode to top
edge of sterilisation
chamber
DE/DB-45
40 mm 35 mm 100 mm
DE/DB-
65/90/150
48 mm 38 mm 100 mm
VE/VB-45/55
35 mm 30 mm 100 mm
VE/VB-65 –
200
47 mm 37 mm 100 mm
Tab. 10: Height and length of the water level electrodes
