HD3G7 module troubleshooting
3. Check to see if t
he problem still exists.
If the problem has been fixed, compare the settings between the factory default
and the user co
nfiguration to find the issue. (See Table 11-6.)
Table 11-6: HD3G7 m odule factory default settings
Men item name
Settings
STATUS 1080 59.94p SMPTE Color Bars
3 Gb/s Level A YCbCr 4:2:2 10b
OUTPUT MODE
Level A
MOVING PICTURE
H Step 0 Sample(s)
V Step 0 Line(s)
Period
1 Frame(s )
Random Disable
TIMING
Vertical
0 Line(s)
Horizontal 0.0000 μs
VIDEO
Y
ON
Cb ON
Cr ON
TRIGGER OUTPUT System Clock
TG8000 Multiformat Test Signal Generator Service Manual 11–17
