Other Operation Procedures
The following parameters can be set for the Controller. For details about how to operate the screen, refer to “Setting LAN”
(page 110). Contact Terumo’s service representative regarding a connection through a switching hub.
Parameter Description
MAC address filtering Sets to perform communication with specific MAC addresses only.
Source IP address IP address for the Controller.
Selects to specify the IP address on the screen, or to obtain it automatically from the
DHCP server.
Subnet mask A number used to determine the subnet (subnetwork) which an IP address belongs to.
Selects to specify the subnet mask on the screen, or to obtain it automatically from the
DHCP server.
Destination IP address IP address of the device to which the communication is being established.
Destination port TCP socket communication port of the device to which the communication is being
established.
Communication between network equipment is conducted with TCP. Network equipment serves as the TCP server, and the
Controller serves as the TCP client.
XML is used as the data format. Export data is output every second.
The beginning of an exported file is an XML declaration and transmitted with an XML instance added.
The XML declaration is described in the following format.
<?xml version="1.0 " encoding="UTF- 8"?>
The XML instance is described in the following format.
<NEO_DATA Year="2013" Month="10" Day="03" Hour="15" Minute="21" Second="15" Sequence="0000000680"
MAC="EF:F9:D9:A8:CD:B4">
<Flow Ch="1"><Value>4.50</Value><Unit>LPM</Unit></Flow>
<Pressure Ch="1"><Value>354</Value><Unit>mmHg</Unit></Pressure>
<Pressure Ch="2"><Value>700</Value><Unit>mmHg</Unit></Pressure>
<Temperature Ch="1"><Value>25.6</Value><Unit>deg C</Unit></Temperature>
<Temperature Ch="2"><Value>4.0</Value><Unit>deg C</Unit></Temperature>
<Speed Ch="1"><Value>925</Value><Unit>RPM</Unit></Speed>
<Alarm><Value>0x0000000000020000112040003E0000000001000000000000</Value></Alarm>
</NEO_DATA>
79
Setting of the Controller
Specification of Network Communication (Format)
