Parts Description
Display Units of the Controller
In this manual, units are written corresponding to the Controller display as follows:
Display on
the LCD touch panel display
Description (unit)
Flow LPM Liters per minute (L/min)
Motor Speed RPM Rotations per minute (r/min)
Optional Accessories
Standard accessories supplied with this system:
● AC power cable (1)
● Instructions for use (1)
● Backup kit (1)
Optional Products
Drive Motor
(Catalogue number: ME
*
SP200M)
Magnets in the motor and in the centrifugal pump are joined magnetically, and the rotating body in the centrifugal pump is rotated
with the DC brushless motor. This Drive Motor can be secured to a pole with the pole clamp.
Cable
Slide hook
Motor
Pole clamp
Magnet cover
Fixed hook
Pump receptacle
Plug
13
Backup Controller (1)
Drive Motor (without a pole clamp) (1)
AC power cable (1)
Screwdriver (+) (1)
Extra screws (to fix the drive motor) (2)
Instructions for use (Backup Controller) (1)
