Terumo CAPIOX EBS Circuit with X coating - Confirming the Setup

Operation Procedure
1. Tap the setup icon on the main screen. (Figure 1-42)
2. Tap the Alarm Setup List icon. (Figure 1-43)
Figure 1-42
3. Confirm the on/off setup of the various functions, the alarm
threshold value and the setup of the safety connection.
(Figure 1-44)
Figure 1-43
Figure 1-44
• To change the setup, refer to the following sections of the “user setup”.
• Setting Pressure Measuring Function

page 85
• Setting Temperature Measuring Function

page 88
• Setting Flow Alarms

page 84
• Setting the Air Bubble Detector Function

page 90
• Setting the Fast Clamp

page 90
• Setting the Safety Connection

page 91
48
Note
Confirming the Setup
