Terumo CAPIOX EBS Circuit with X coating User Manual

Operation Procedure
1. Attach the CAPIOX EBS Circuit Holder to the IV pole, and
secure it with the knob. (Figure 1-79)
Attach it on the opposite side of the cylinder holder.
• The CAPIOX EBS Circuit Holder is secured.
Figure 1-79
Refer to the steps 1 to 3 of page 38 “Connecting to Fast Clamp  Using the Fast Clamp Attachment (for EBS)”.
1. Attach the basket to a pole, and secure it with the knob.
(Figure 1-80)
Position the basket so that it does not interfere with nearby components.
• The basket is secured.
Figure 1-80
63
Attaching the CAPIOX EBS Circuit Holder
Check
Attaching the Fast Clamp Attachment (for EBS)
Attaching the Basket
Check
IV pole
Knob
CAPIOX EBS Circuit Holder
Basket
Knob
