Terumo CAPIOX EBS Circuit with X coating - Attaching the Oxygen Cylinder

Operation Procedure
Figure 1-76
1. Attach the cylinder holder to the rear side pole, and secure
it with the knobs. (Figure 1-77)
• The cylinder holder is secured.
Figure 1-77
2. Place the oxygen cylinder into the cylinder holder.
(Figure 1-78)
Secure the oxygen cylinder with the belt when you move the cart.
Figure 1-78
62
IV pole
Gas blender
Attaching the Oxygen Cylinder
Check
Cylinder holder
Knobs
Pole
Oxygen cylinder
Belt
