Various menu settings
3. Tap [Start]. (Figure 3-44)
Count down starts.
When count down starts, [Start] changes to [Stop].
• The count down continues even if another screen is opened.
4. When the count down is finished, “Count-down Ended” is
displayed on the message area with a sound. (Figure 3-45)
5. Tap “Count-down Ended”. (Figure 3-46)
Figure 3-44
Figure 3-45
• If the count down screen is displayed when the count down ends, the screen of
step 6 is displayed.
Figure 3-46
6. When the screen to confirm timer end is displayed, tap [OK]
or [Cancel]. (Figure 3-47)
[OK]: Returns the timer to the set time and restarts the count down.
[Cancel]: Ends the use of the count down timer.
Tap [OK] or [Cancel] to stop the sound.
Figure 3-47
Data (motor speed, flow, pressure, temperature) and events are recorded. (History function)
Trend chart
Motor speed, flow, and pressure which have been recorded since power was turned on are displayed in the chart.
1. Select a time axis. (Figure 3-48)
[24h]: Displays the data of the last 24 hours.
[12h]: Displays the data of the last 12 hours.
[3h]: Displays the data of the last 3 hours.
Tap
or
to adjust the time frame by one-hour intervals. It can
retrieve up to the previous twelve hours.
Figure 3-48
95
