Various menu settings
The following admin setup values can be set:
• The on/off status of the temperature measuring function
• Threshold value of the Pressure Alert (setup range: 0.0 to 50.0°C)
For details about how to set, refer to “Setting Temperature Measuring Function” (page 88).
• The changes to the setting will take effect after restarting.
The admin setup value for the fast clamp function can be set on/off.
For details about how to set, refer to “Setting the Fast Clamp” (page 90).
• The changes to the setting will take effect after restarting.
The following admin setup values can be set:
• The on/off status of the air bubble detector function
• Air bubble detection sensitivity (High/Medium/Low)
For details about how to set the preset value of the air bubble detector function, refer to “Setting the Air Bubble Detector Function”
(page 90).
This section describes the setup procedures for sensitivity of the air bubble detector function.
• The on/off setting for the air bubble detector function will take effect after restarting. The sensitivity setting will take effect
instantly.
1. Tap the Air Bubble icon. (Figure 3-69)
The Air Bubble screen opens.
Figure 3-69
2. Tap the Sensitivity you want to set. (Figure 3-70)
[High]: Air bubbles larger than 0.05 cm
3
are detected (at flow of 4.20 LPM
(L/min) or less)
[Medium]: Air bubbles larger than 0.2 cm
3
are detected (at flow of 7.00 LPM
(L/min) or less)
[Low]: Air bubbles larger than 0.5 cm
3
are detected (at flow of 7.00 LPM
(L/min) or less)
Figure 3-70
104
Temperature Preset
Note
Setting the Fast Clamp
Note
Setting the Air Bubble Detector Function
Note
To Next Page
