Terumo CAPIOX EBS Circuit with X coating - Setting the Communication with CDI

Various menu settings
 Setting the On/Off status of the LAN communication
1. Tap [On/Off] of [Controller]. (Figure 3-116)
The On/Off screen opens.
2. Select [On] or [Off]. (Figure 3-117)
When [Off] is selected, the setting values thus far are maintained, but
communication is not performed.
Figure 3-116
3. Tap [OK] to complete the setting. (Figure 3-118)
Figure 3-117
Figure 3-118
• If you do not tap [OK], the changes to the setting will not take effect.
The on/off status of the CDI communication can be set.
1. Tap the CDI icon. (Figure 3-119)
The CDI screen opens.
Figure 3-119
116
Note
Setting the Communication with CDI
