Operation Procedure
You can perform the priming easily by using the auto-priming function.
1. Start the auto-priming after filling the priming solution. The
following two methods are available.
When auto-priming is started, the indicators light on the auto priming icon
(green) and on the auto-priming button (orange). The centrifugal pump
rotates intermittently in auto-priming mode. When CAPIOX EBS Circuit
with X coating is used, the air bubbles in the circuit will be removed through
oxygenator membrane.
<<Operation from the main screen>>
Tap the auto priming icon. (Figure 1-45)
<<Operation from the control panel>>
Press the auto priming button on the control panel.
(Figure 1-46)
Auto priming icon
Figure 1-45
• Auto-priming can be started only when the motor speed is “0”.
Figure 1-46
2. Remove air from the branch lines while the centrifugal
pump is rotating.
Remove the port cap of the sampling line of the oxygenator and attach
a syringe. And then, open the three way stopcock. Remove air of the
oxygenator connection section by lightly tapping with your palm.
3. After confirming that the air bubbles in the blood circuit
have been removed, stop auto-priming.
<<Operation from the main screen>>
Tap the auto priming icon. (Figure 1-45)
<<Operation from the control panel>>
Press the auto priming button on the control panel.
(Figure 1-46)
• The motor speed becomes “0”.
• The auto priming icon and the auto priming button indicators are turned off.
49
Note
Auto-priming
• When priming, if a significant amount of air enters the centrifugal pump causing the pump to idle, stop the rotation of the
pump. Remove the air and start priming again.
Caution
Checks
Auto priming button
