Operation Procedure
1. Insert the AC power cable into the AC power inlet until you
hear a click. (Figure 1-5)
When it is fully inserted, the AC power cable is locked in the AC power inlet.
• The AC power cable will not disconnect even if you pull it toward you while holding
the connector of the AC power cable.
When removing the AC power cable, pull it out straight while pressing the
latches as shown in the figure. (Figure 1-6)
Figure 1-5
2. Plug in the AC power cable to the grounded AC power
source.
Figure 1-6
• The AC power lamp is lit.
• When the AC power cable is connected to the grounded AC power source, the
battery can be charged even if the system power is turned off. The charge lamp is
lit while charging the battery.
32
Check
Check
Note
AC power inlet
AC power cable
Latches
To Next Page
