Other Operation Procedures
2. Clamp the blood line of the patient side of the Fast Clamp
with forceps. (Figure 2-5)
Figure 2-5
3. Remove the air bubble from the blood circuit.
For details about how to handle, refer to “Alarms and Troubleshooting”
(page 132).
4. Tap [Air Bubble Detected Alarm] on the message area,
and after confirming the displayed message, tap [OK].
(Figure 2-6)
The Air Bubble Detected Alarm is cleared, and “Air Bubble Detected Alarm”
on the message area is turned off.
• The Air Bubble Detected Alarm can also be cleared by performing the step 5 or
step 6.
Figure 2-6
5. Pull up the lever of the Fast Clamp until you hear a click,
and remove the occlusion with the Fast Clamp. (Figure 2-7)
“Air Bubble: Clamp Close” on the message area is turned off.
• After pulling up the lever, the lever has returned to the original position.
• If the lever does not return to the original position, pull down the lever. If it does
not return to the original position, a failure may have occurred.
Stop using the system immediately, and contact Terumo’s service representative.
Figure 2-7
69
Note
Check
Note
Blood line Fast Clamp
Forceps
Lever
Side of the patient
To Next Page
