Configured system dimensions
Allow space for the congured instrument. A typical setup with a co-located
minitower computer is shown below.
Note: Dimensions are rounded to the nearest whole or half unit.
27 cm (10.5 in.)
50 cm (20 in.)
15 cm (6 in.)
40 cm (16 in.)
30 cm (12 in.)
207 cm (81.5 in.)
Appendix C Instrument specification and layout
Configured system dimensions
