20
COMPONENTS
(5) REF measurement value:
Displays the REF measurement value.
Of measurement values, the latest data is displayed on the screen.
Figures only: When the measurement was done correct.
Figures with *: When the reliability of measurement is low.
ERROR: When the measurement was not done correctly.
(6) KRT measurement value:
Displays the KRT measurement value.
The latest measurement data is displayed on the screen.
In the INITIAL MENU screen, the display of HV (horizontal/vertical
direction) and R1R2 (major meridian direction) can be switched.
(See page 76)
(7) Number of REF/KRT measurements:
Displays the number of REF and KRT measurements.
(8) Function menu: Display the function button under REF/KRT mode.
For details, see "CONTROL PANEL COMPONENTS (REF/KRT
MODE)" on page 13.
(9) Measurement result unit setting:
Displays the unit of the result of KRT measurement (diopter or mm).
Diopter setting :
mm setting :
The setting can be changed in the INITIAL MENU screen. (See page
75)
(10) Set value of CYLINDER sign:
Displays the CYL set value.
The setting can be changed in the INITIAL MENU screen. (See page
77)
(11) VD setting: Displays the set value of vertex distance.
The setting can be changed in the INITIAL MENU screen. (See page
73)
(12) Outer alignment mark:
Used to get coarse alignment in aiming at the patient's eye.
(13) Alignment mark: Indicates the starting area of auto alignment.
(14) IOL mark: Displayed when the IOL button is ON.
(15) Fixation lamp mark:Displayed when the Fixation button is Hi.
(16) Selected measuring eye mark:
Selected patient's eye is shown.
:Both eyes are measured continuously.
:Only the right eye is measured. When fully
automatic measurement mode is selected, only the right
eye is measured repeatedly.
:Only the left eye is measured. When fully auto-
matic measurement mode is selected, only the left eye is
measured repeatedly.
continuous measurement is set in initial settings.
After or is selected, automatically return to initial setting
(continuous measurement), if printing is carried out.
R L
R R/K T/P
L R/K T/P
R L
R L
