Configuration Guide 142
Configuring 802.1Q VLAN 802.1Q VLAN Configuration
2
802.1Q VLAN Configuration
To complete 802.1Q VLAN configuration, follow these steps:
1) Configure the port parameters;
2) Configure the VLAN, including creating a VLAN and adding the configured port to the
VLAN.
2.1 Using the GUI
2.1.1 Configuring the PVID of the Port
Choose the menu L2 FEATURES > VLAN > 802.1Q VLAN > Port Config to load the
following page.
Figure 2-1 Configuring the Port
Select a port and configure the parameters. Click Apply.
PVID Set the default VLAN ID of the port. Valid values are from 1 to 4094. It is used
mainly in the following two ways:
When the port receives an untagged packet, the switch inserts a VLAN tag to the
packet based on the PVID.
