Configuring QoS Bandwidth Control Configuration
Configuration Guide
445
3.1.2 Configuring Storm Control
Choose the menu QoS > Bandwidth Control > Storm Control to load the following page.
Figure 3-2 Configuring Storm Control
Follow these steps to configure the Storm Control function:
1) Select the desired port and configure the upper rate limit for forwarding broadcast
packets, multicast packets and UL-frames (Unknown unicast frames).
Rate Mode Specify the Rate Mode for the broadcast threshold, multicast threshold and UL-
Frame threshold on the desired port.
kbps: The switch will limit the maximum speed of the specific kinds of traffic in
kilo-bits per second.
ratio: The switch will limit the percentage of bandwidth utilization for specific
kinds of traffic.
Broadcast
Threshold (0-
1,000,000)
Specify the upper rate limit for receiving broadcast packets. The valid values
differ among different rate modes. The value 0 means the broadcast threshold is
disabled. The broadcast traffic exceeding the limit will be processed according to
the Action configurations.
Multicast
Threshold (0-
1,000,000)
Specify the upper rate limit for receiving multicast packets. The valid values
differ among different rate modes. The value 0 means the multicast threshold is
disabled. The multicast traffic exceeding the limit will be processed according to
the Action configurations.
