Configuration Guide 260
Configuring Layer 2 Multicast Multicast Filtering Configuration
Follow these steps to bind the profile to ports and configure the corresponding parameters
for the ports:
1) Select one or more ports to configure.
2) Specify the profile to be bound, and configure the maximum groups the port can join
and the overflow action.
Profile ID Specify the ID of an existing profile to bind the profile to the selected ports. One
port can only be bound to one profile.
Maximum
Groups
Enter the number of multicast groups the port can join. Valid values are from 1 to
511.
Overflow Action Select the action the switch will take with the new multicast member groups when
the number of multicast groups the port has joined exceeds the maximum.
Drop: Drop all subsequent membership report messages to prevent the port
joining a new multicast groups.
Replace: Replace the existing multicast group that has the lowest multicast MAC
address with the new multicast group.
LAG Displays the LAG the port belongs to.
Operation Click Clear Profile to clear the binding between the profile and the port.
3) Click Apply.
5.2 Using the CLI
5.2.1 Creating the Multicast Profile
You can create multicast profiles for both IPv4 and IPv6 network. With multicast profile,
the switch can define a blacklist or whitelist of multicast groups so as to filter multicast
sources.
Creating IGMP Profile (Multicast Profile for IPv4)
Step 1 configure
Enter global configuration mode.
Step 2 ip igmp profile
id
Create a new profile and enter profile configuration mode.
